| CPU |
AMD Ryzen™ Embedded V1500B 4-core/8-thread 2.2 GHz processor |
| CPU Architecture |
64-bit x86 |
| Floating Point Unit |
|
| Encryption Engine |
(AES-NI) |
| Hardware-accelerated Transcoding |
Optional via a PCIe graphics card |
| System Memory |
4 GB SODIMM DDR4 (1 x 4 GB) |
| Maximum Memory |
64 GB (2 x 32 GB) |
| Memory Slot |
2 x SODIMM DDR4
Support ECC memory
For dual-DIMM configuration, you must use a pair of identical DDR4 modules.
|
| Flash Memory |
5GB (Dual boot OS protection) |
| Drive Bay |
8 x 3.5-inch SATA 6Gb/s, 3Gb/s
The system is shipped without HDD.
For the HDD compatibility list,
|
| Drive Compatibility |
3.5-inch SATA hard disk drives
2.5-inch SATA hard disk drives
2.5-inch SATA solid state drives |
| Hot-swappable |
|
| M.2 Slot |
2 x M2 2280 (PCIe Gen3 x 1) |
| SSD Cache Acceleration Support |
|
| GPU pass-through |
|
| 2.5 Gigabit Ethernet Port (2.5G/1G/100M) |
2 (2.5G/1G/100M/10M) |
| 5 Gigabit Ethernet Port (5G/2.5G/1G/100M) |
Optional via a network adapter |
| 10 Gigabit Ethernet Port |
Optional via a network adapter |
| Wake on LAN (WOL) |
Only the 2.5GbE port
|
| Jumbo Frame |
|
| PCIe Slot |
1 x PCIe Gen3 x8 |
| USB 3.2 Gen 2 (10Gbps) Port |
4 (2 x Type A, 2 x Type C) |
| HDMI Output |
Optional via a PCIe graphics card |
| Form Factor |
2U Rackmount |
| LED Indicators |
HDD 1-8, Status, LAN, USB, Power |
| Buttons |
Power, Reset |
| Dimensions (HxWxD) |
89 × 482 × 297.4 mm |
| Weight (Net) |
8.15 kg |
| Weight (Gross) |
10.92 kg |
| Operating Temperature |
0 - 40 °C (32°F - 104°F) |
| Storage Temperature |
-20 - 70°C (-4°F - 158°F) |
| Relative Humidity |
5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
| Power Supply Unit |
300W PSU(x2), 100 - 240V |
| Power Consumption: HDD Sleep Mode |
32.19 W |
| Power Consumption: Operating Mode, Typical |
58.14 W
Tested fully populated with WD10EFRX hard drives.
|
| Fan |
3 x 60mm, 12VDC |
| System Warning |
Buzzer |
| Max. Number of Concurrent Connections (CIFS) - with Max. Memory |
2000 |
