| PERFORMANCE |
| Processor |
Intel® Core™ i7-13700K, 16C (8P + 8E) / 24T, Max Turbo up to 5.4GHz, P-core 3.4 / 5.3GHz, E-core 2.5 / 4.2GHz, 30MB
|
| Processor Sockets |
1x FCLGA1700
|
| Integrated Graphics |
Integrated Intel® UHD Graphics 770
|
| Discrete Graphics |
1x NVIDIA® T1000 8GB
|
| Chipset |
Intel® W680 Chipset
|
| Memory |
2x 16GB UDIMM DDR5-4400 Non-ECC
|
| Memory Slots |
4 DDR5 DIMM slots, 2 channels capable
|
| Max Memory |
Up to 128GB (4x 32GB DDR5 UDIMM)
|
| M.2 SSD RAID Controller |
Integrated NVMe® Controller
|
| M.2 SSD Drive |
1x 1TB SSD M.2 2280 PCIe® 4.0x4 Performance NVMe® Opal
|
| HDD Controller |
Onboard Intel® RSTe SATA RAID
|
| SATA/SAS Drive |
None
|
| Storage Support |
Up to five drives (4x HDD + 1x M.2 SSD) or six drives (3x HDD + 3x M.2 SSD) • 3.5" HDD up to 6TB each • 2.5" HDD up to 1TB each • M.2 SSD up to 4TB or 2TB each (see Storage Type)
|
| Optical |
None
|
| Audio Chip |
High Definition (HD) Audio, Realtek® ALC897Q-CG codec
|
| Power Supply |
750W Platinum Fixed
|
| DESIGN |
| Keyboard |
USB Traditional Keyboard, Black, Turkish
|
| Mouse |
USB Calliope Mouse, Black
|
| Expansion Slots |
Supports four PCIe® slots with two PCIe 4.0 x16 and two PCIe 3.0 x1. • Slot 1: PCIe 4.0 x16, full height, full length, 75W, double-width • Slot 2: PCIe 3.0 x1, full height, half length, 25W • Slot 3: PCIe 4.0 x16 (x4 lanes), full height, half length, 25W • Slot 4: PCIe 3.0 x1, full height, half length, 25W
|
| M.2 Slots |
- Up to 3x M.2 SSD: • 2 via onboard slot, can't be available when 4th HDD is selected • 1 via Single M.2 to PCIe® adapter
- One M.2 slot (for WLAN)
|
| Bays |
Up to four disk bays: • Bay 1 supports one 3.5" / 2.5" HDD, standard • Bay 2 supports one 3.5" / 2.5" HDD, optional • Bay 3 supports one 3.5" / 2.5" HDD, optional • Bay 4 supports one 3.5" / 2.5" HDD, optional • Front Access HDD Bay supports one 3.5" / 2.5" HDD, optional, occupies Bay 3 location
|
| Dimensions (WxDxH) |
180 x 370 x 415 mm (7.09 x 14.57 x 16.34 inches)
|
| Weight |
13.61 kg (30.0. lbs, maximum configuration)
|
| CONNECTIVITY |
| Onboard Ethernet |
Intel® I219-LM, 1x GbE RJ-45
|
| Optional Ethernet |
None
|
| WLAN + Bluetooth |
None
|
| Card Reader |
SD Card Reader
|
| Front Ports |
- 1x USB-C® 3.2 Gen 2 (support data transfer)
- 2x USB 3.2 Gen 1
- 2x USB 3.2 Gen 2
- 1x headphone / microphone combo jack (3.5mm)
- 1x microphone (3.5mm)
|
| Rear Ports |
- 4x USB 3.2 Gen 1 (one supports Smart Power On)
- 1x HDMI® 2.1 TMDS
- 2x DisplayPort™ 1.4
- 1x Ethernet (RJ-45)
- 1x line-out (3.5mm)
|
| Optional Rear Ports (configured) |
None
|
| SECURITY & PRIVACY |
| Security Chip |
Discrete TPM 2.0, TCG certified, FIPS 140-2 certified
|
| Physical Locks |
- Kensington® Security Slot™, 3 x 7 mm
- Padlock Loop
|
| Cover Lock |
None
|
| Cable Lock |
No Cable
|
| Chassis Intrusion Switch |
None
|
| MANAGEABILITY |
| System Management |
Intel® vPro® Enterprise with Intel AMT 16
|
| SERVICE |
| Base Warranty |
3-year, Onsite
|
| Included Upgrade |
1Y Premier Support from 3Y Onsite Windchill bundles (CPN)
|
| Green Certifications |
- ENERGY STAR® 8.0
- EPEAT™ Gold Registered
- ErP Lot 3
- RoHS compliant
- TCO Certified 9.0
|
| ISV Certifications |
Please visit ISV certifications for Lenovo® Workstations
|
| SOFTWARE |
| Operating System |
Windows® 11 Pro, Turkish / English
|
| Bundled Software |
None
|
