| PERFORMANCE |
| Processor |
Intel® Core™ i7-14700, 20C (8P + 12E) / 28T, Max Turbo up to 5.4GHz, P-core 2.1 / 5.3GHz, E-core 1.5 / 4.2GHz, 33MB
|
| Processor Sockets |
1x FCLGA1700
|
| Integrated Graphics |
Integrated Intel® UHD Graphics 770
|
| Discrete Graphics |
1x NVIDIA® T1000
|
| Chipset |
Intel® W680 Chipset
|
| Memory |
1x 16GB UDIMM DDR5-4400 Non-ECC
|
| Memory Slots |
Four DDR5 UDIMM slots, dual-channel capable
|
| Max Memory |
Up to 128GB (4x 32GB DDR5 UDIMM)
|
| PCIe NVMe Controller |
Integrated NVMe® Controller
|
| PCIe NVMe Drive |
1x 1TB SSD M.2 2280 PCIe® 4.0x4 Performance NVMe® Opal
|
| SATA Controller |
Onboard Intel® RSTe SATA RAID
|
| SATA/SAS Drive |
None
|
| Storage Support |
Up to 2x 3.5" SATA HDD; also supports up to 3x M.2 SSD (two by onboard, one by M.2 to PCIe® adapter) • 3.5" HDD up to 4TB each • Onboard M.2 SSD up to 4TB each • M.2 SSD by M.2 to PCIe adapter up to 2TB
|
| Optical |
None
|
| Audio Chip |
High Definition (HD) Audio, Realtek® ALC897Q-CG codec
|
| Power Supply |
500W Platinum Fixed
|
| DESIGN |
| Keyboard |
USB Calliope Keyboard, Black, Turkish
|
| Mouse |
USB Calliope Mouse, Black
|
| Expansion Slots |
Supports four PCIe® slots with two PCIe 4.0 x16 and two PCIe 3.0 x1. • Slot 1: PCIe 4.0 x16, full height, full length, 75W, double-width • Slot 2: PCIe 3.0 x1, full height, half length, 25W • Slot 3: PCIe 4.0 x16 (x4 lanes), full height, half length, 25W • Slot 4: PCIe 3.0 x1, full height, half length, 25W
|
| Bays |
Three internal disk bays, up to two 3.5" bays plus one 2.5" bay: • Bay 1 supports one 3.5" HDD, standard; or one 2.5" HDD / SSD, optional • Bay 2 supports one 3.5" HDD or 2.5" HDD / SSD, optional • Bay 3 supports one 2.5" HDD / SSD, optional • Front Access HDD Bay supports one 3.5" HDD or 2.5" HDD / SSD, optional, occupies Bay 2 location
|
| Dimensions (WxDxH) |
170 x 315.35 x 376 mm (6.7 x 12.4 x 14.8 inches, with feet)
|
| Weight |
9.67 kg (21.32 lbs, maximum configuration)
|
| CONNECTIVITY |
| Onboard Ethernet |
Intel® I219-LM, 1x GbE RJ-45
|
| Optional Ethernet |
None
|
| WLAN + Bluetooth |
None
|
| Card Reader |
SD Card Reader
|
| Front Ports |
- 1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), data transfer only
- 2x USB-A (USB 5Gbps / USB 3.2 Gen 1)
- 2x USB-A (USB 10Gbps / USB 3.2 Gen 2)
- 1x headphone / microphone combo jack (3.5mm)
- 1x microphone (3.5mm)
|
| Rear Ports |
- 4x USB-A (USB 5Gbps / USB 3.2 Gen 1), one supports Smart Power On
- 1x HDMI® 2.1 TMDS
- 2x DisplayPort™ 1.4
- 1x Ethernet (RJ-45)
- 1x line-out (3.5mm)
|
| Optional Rear Ports (configured) |
None
|
| SECURITY & PRIVACY |
| Security Chip |
Discrete TPM 2.0, TCG certified, FIPS 140-2 certified
|
| Physical Locks |
- Kensington® Security Slot™, 3 x 7 mm
- Padlock Loop
|
| Cover Lock |
None
|
| Cable Lock |
No Cable
|
| Chassis Intrusion Switch |
None
|
| MANAGEABILITY |
| System Management |
Intel® vPro® Enterprise with Intel AMT 16
|
| SERVICE |
| Base Warranty |
3-year, Onsite
|
| Included Upgrade |
None
|
| CERTIFICATIONS |
| Green Certifications |
- ENERGY STAR® 8.0
- EPEAT™ Gold Registered
- ErP Lot 3
- RoHS compliant
- TCO Certified 9.0
|
| ISV Certifications |
Please visit ISV certifications for Lenovo® Workstations
|
| SOFTWARE |
| Operating System |
Windows® 11 Pro, Turkish / English
|
| Bundled Software |
None
|
