| Hardware features |
| Network standards |
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3z, IEEE 802.3x, IEEE 802.1p, IEEE 802.1q, IEEE 802.1w, IEEE 802.1d, and IEEE 802.1s |
| LED indicators |
One Link/Act LED indicator for each port
One Power LED indicator
One SYS LED indicator |
| Fixed ports |
8 x 10/100/1000Base-T Ethernet port
16 x 1000Base-X SFP slot |
| Lightning protection |
Port: 6 kV
Power supply: 6 kV |
| Forwarding mode |
Store-and-forward |
| Switching capacity |
48 Gbps |
| Packet forwarding rate |
35.7 Mpps |
| Switching buffer |
12 Mbit |
| MAC address table |
16K |
| Input voltage |
100 - 240V AC 50/60Hz |
| Dimensions |
440 mm * 179.6 mm * 44 mm(L x W x H) |
| Environment |
Operating temperature: 0°C - 45°C
Operating humidity: (10% - 90%)RH, non-condensing
Storage temperature: -40°C - 70°C
Storage humidity: (5% - 90%)RH, non-condensing |
| Certificates |
CCC, FCC, CE, RoHS |
| Software features |
| Security features |
Support ARP receiving limit
Support discarding unknown MAC addresses
Support DoS attack defense
Support 802.1X security authentication
Support RADIUS authentication |
| VLAN |
Support 802.1Q VLAN
Support VLAN layer-3 interface
Support three port modes: Access, Trunk and Hybrid |
| DHCP |
Support DHCP server
Support DHCP relay
Support DHCP snooping
Support Option 82 policy configuration |
| L3 routing |
Support inter-VLAN routing
Support IPv4 static routing
Support dynamic ARP and static ARP
Support ARP aging configuration |
| Port aggregation |
Support static aggregation
Support LACP dynamic aggregation
Support a maximum of 32 aggregation groups and a maximum of 8 member ports in each group |
| STP |
Support IEEE 802.1d STP (Spanning Tree Protocol)
Support IEEE 802.1w RSTP (Rapid Spanning Tree Protocol)
Support IEEE 802.1s MSTP (Multiple Spanning Tree Protocol)
Support edge ports
Support BPDU statistics |
| Multicast |
Support IGMP snooping v1/v2/v3
Support fast leave |
| Port mirroring |
Support N : 1 port mirroring |
| QoS |
Support SP (Strict Priority)
Support SWRR (Simple Weighted Round Robin)
Support WRR (Weighted Round Robin)
Support 802.1P port trust mode
Support DSCP port trust mode
Support a maximum of 8-queue service quality mapping
Support Tail Drop
Support storm suppression
Support port speed limit |
| ACL |
Support MAC ACL
Support IPv4 ACL |
| Loading and upgrade |
Support FTP/TFTP/HTTP upgrade
Support configuration import and export |
| Cloud management |
Support configuration delivery from IMS cloud platform
Support log reporting and fault detection
Support remote maintenance: reboot, backup, and upgrade |
| Local visualization management |
Support discovery of such network devices as routers, switches, APs based on LLDP
Support IP camera discovery based on ONVIF protocol
Support automatic generation of topology
Support local view and main view
Support online/offline status detection for devices
Support remote IP camera reboot
Support loop alerts
Support custom device types and device names |
| Management and maintenance |
Support CLI configuration
Support Telnet remote configuration
Support configuring through Console port
Support SNMP v1/v2/v3
Support web management
Support system logs
Support log classification
Support NTP
Support Ping & Tracert tests
Support memory and CPU monitoring |
