Bu ürün geçici olarak temin edilememektedir
Ürün temin edildiğinde tekrar satışa sunulacaktır.
Teknik Bilgiler:
Soket Tipi | Lga 1200 |
Chipset | H470 |
Bellek Tipi | DDR4 |
Bellek Kapasitesi | 64 GB |
Form Faktörü | Micro ATX |
Ram Slot Sayısı | 2 Adet |
Dahili Grafik | Var |
HDMI Çıkışı | Var |
CPU:
LGA1200 package:
11th Generation Intel Core i9 processors/Intel Core i7 processors/Intel Core i5 processors
10th Generation Intel Core i9 processors/Intel Core i7 processors/Intel Core i5 processors/Intel Core i3 processors/Intel Pentium processors/Intel Celeron processors
L3 cache varies with CPU
Chipset:
Intel H470 Express Chipset
Memory:
2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) of system memory
Onboard Graphics:
Integrated Graphics Processor-Intel HD Graphics support:
1 x HDMI port, supporting a maximum resolution of 4096x2160@30 Hz
Audio:
Realtek Audio CODEC
High Definition Audio
2/4/5.1/7.1-channel
LAN:
Realtek GbE LAN chip (1 Gbps/100 Mbps/10 Mbps)
Internal I/O Connectors:
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x CPU fan header
1 x system fan header
1 x RGB LED strip header
1 x M.2 Socket 3 connector
2 x SATA 6Gb/s connectors
1 x front panel header
1 x front panel audio header
1 x USB 3.2 Gen 1 header
1 x USB 2.0/1.1 header
1 x serial port header
1 x Clear CMOS jumper
Back Panel Connectors:
1 x HDMI port
2 x USB 3.2 Gen 1 ports
4 x USB 2.0/1.1 ports
1 x RJ-45 port
3 x audio jacks
I/O Controller:
iTE I/O Controller Chip
BIOS:
1 x 128 Mbit flash
Use of licensed AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Form Factor:
Micro ATX Form Factor; 22.6cm x 18.5cm
Soket Tipi | Lga 1200 |
Chipset | H470 |
Bellek Tipi | DDR4 |
Bellek Kapasitesi | 64 GB |
Form Faktörü | Micro ATX |
Ram Slot Sayısı | 2 Adet |
Dahili Grafik | Var |
HDMI Çıkışı | Var |
