Cudy RE1800 AX1800 Mesh Wi-Fi 6 Range Extender

RE1800

Chipset

MT7621A+MT7905DAN +MT7975DN

CPU Details

880 MHz Dual-Core, MIPS1004Kc

Flash/ROM

8 MB (64 Mbit ) NOR

DDR/RAM

128 MB (1 Gbit) DDR3

5 GHz Wi-Fi Speed

1201 Mbps

2.4 GHz Wi-Fi Speed

574 Mbps

5 GHz Wi-Fi Streams

2T2R (2×2 MIMO)

2.4 GHz Wi-Fi Streams

2T2R (2×2 MIMO)

Wi-Fi Antennas

2× Fixed

2.4 GHz Antenna Gain Max

3.49dBi

5 GHz Antenna Gain Max

6.24dBi

FEM or PA/LNA

5 GHz: 2× Internal

2.4 GHz: 2× Internal

Range Performance

Max: 150 m (492 ft)
Indoor WiFi range varies depending on the layout and wall materials. See Wall Performance spec for placement suggestions.

Wall Performance

One wooden walls with thickness < 10 cm (4'')
One concrete wall with thickness < 20 cm (7'')

Gigabit RJ45 Ports

1

LED

Signal Strength

WPS

Power

Physical Buttons

WPS Button

Reset Button

Power Input

AC Plug

Power Input Note

EU, US, UK Plug are Available

Power Methods

AC

AC

100V ~ 240V

Wi-Fi Standards

Wi-Fi 6

Max Wi-Fi Modulation

1024-QAM

Wi-Fi Efficiency

OFDMA

MU-MIMO

BSS Color

Max Capacity

256

Recommended Client Upper Limit

40

Max Wi-Fi Channel Width

80 MHz

Wi-Fi Security

WPA-PSK (WPA/WPA2/WPA3)

WPS

true

Operation Modes

Access Point

Range Extender

Mesh

Cudy Mesh Satellite

Mesh Backhaul

Wireless Backhaul

Wired Backhaul

Multi-Band Backhaul

true

LED Control

true

Local Control Method

Config Web Page

App Control

Remote Control Method

App Control

Firmware Upgrade

Local Update

App (Over the Air)

Online Update

Reliability

Timed Reboot

Backup and Restore

Panel

Connected Devices, Host Network Status, Wi-Fi Status, LAN Status, System Version

Charts

Mesh Topology

Diagnostic Tools

Ping

Traceroute

NSLookup

System Log
