APC SMT1000RMI2UC Smart-UPS 1000VA LCD RM 2U 230V with SmartConnect

Output

Max Configurable Power (Watts)

700 Watts / 1.0kVA

Output Voltage Note

Configurable for 220 : 230 or 240 nominal output voltage

Output Voltage Distortion

Less than 5 %

Output Frequency (sync to mains)

50/60 Hz +/- 3 Hz Sync to mains

Other Output Voltages

220, 240

Topology

Line interactive

Waveform type

Sine wave

Transfer Time

6 ms typical : 10 ms maximum

Input

Input frequency

50/60 Hz +/- 3 Hz Auto-sensing

Input voltage range for main operations

151 - 302 Adjustable, 160 - 286V

Number of Power Cords

1

Other Input Voltages

220, 240

Batteries & Runtime

Battery type

Lead-acid battery

Typical recharge time

3hour(s)

Expected Battery Life (years)

4 - 6

RBC Quantity

1

Battery Charge Power (Watts)

112 Watts

Interface Port(s)

RJ-45 Serial, SmartSlot, USB

Control panel

Multifunction LCD status and control console

Audible Alarm

Alarm when on battery : distinctive low battery alarm : configurable delays

Emergency Power Off (EPO)

Optional

Available SmartSlot™ Interface Quantity

1

Surge Protection and Filtering

Surge energy rating

459Joules

Filtering

Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449

Physical

Maximum Height

86MM, 8.6CM

Maximum Width

432MM, 43.2CM

Maximum Depth

477MM, 47.7CM

Net Weight

22.5KG

Shipping weight

31.45KG

Shipping Height

251MM, 25.1CM

Shipping Width

594MM, 59.4CM

Shipping Depth

603MM, 60.3CM

Color

Black

Units per Pallet

8.0

Environmental

Operating Temperature

0 - 40 °C

Operating Relative Humidity

0 - 95 %

Operating Elevation

0 - 3048meters

Storage Temperature

-15 - 45 °C

Storage Elevation

0 - 15240meters

Audible noise at 1 meter from surface of unit

45.0dBA

Online thermal dissipation

56.0BTU/hr

Conformance

Approvals

CSA, EAC, EN/IEC 62040-1, EN/IEC 62040-2, RCM, VDE

Standard warranty

3 years repair or replace (excluding battery) and 2 years for battery

EAN Numarası: 731304332985
