| Scanner Type |
ADF (Automatic Document Feeder), Duplex |
Scanning Speed (1) (A4 Portrait)
(Color (2)/Grayscale (2)/Monochrome (3)) |
Simplex: 25 ppm (200/300 dpi)
Duplex: 50 ipm (200/300 dpi) |
| Image Sensor Type |
Single line CMOS-CIS x 2 (front x 1, back x 1) |
| Light Source |
3 Color LED x 2 (front x 1, back x 1) |
| Optical Resolution |
600 dpi |
Output Resolution (4)
(Color / Grayscale / Monochrome) |
50 to 600 dpi (adjustable by 1 dpi increments), 1,200 dpi (driver) (5) |
| Output Format |
Color: 24-bit, Grayscale: 8-bit, Monochrome: 1-bit |
| Background Colors |
White |
| Document Size |
Maximum |
216 x 355.6 mm (8.5 x 14 in.) |
| Minimum |
52 x 74 mm (2.0 x 2.9 in.) |
| Long Page Scanning (6) |
3,048 mm (120 in.) |
| Paper Weight (Thickness) |
Paper |
50 to 209 g/m2 (13.4 to 56 lb) (7) |
| Plastic Card |
0.76 mm (0.0299 in.) or less (8) |
| ADF Capacity (9)(10) |
50 sheets (A4 80 g/m2 or Letter 20 lb) |
| Expected Daily Volume (11) |
4,000 sheets |
| Multifeed Detection |
Overlap detection (Ultrasonic sensor) |
| Interface (12) |
USB 2.0 / USB 1.1 |
| Power Requirements |
AC 100 to 240 V ±10 % |
| Power Consumption |
Operating Mode |
18 W or less |
| Sleep Mode |
1.6 W or less |
| Auto Standby (Off) Mode |
0.4 W or less |
| Operating Environment |
Temperature |
5 to 35 °C (41 to 95 °F) |
| Relative Humidity |
20 to 80% (non-condensing) |
| Environmental Compliance |
ENERGY STAR®, RoHS |
| Dimensions (13) (W x D x H) |
298 x 135 x 133 mm (11.7 x 5.3 x 5.2 in.) |
| Weight |
2.5 kg (5.5 lb) |
| Supported Operating System |
Windows® 10 (14), Windows® 8.1, Windows® 7, Windows Server® 2019, Windows Server® 2016, Windows Server® 2012 R2, Windows Server® 2012, Windows Server® 2008 R2, Windows Server® 2008 (15), Linux (Ubuntu) (16)(17) |
| Included Software / Drivers |
PaperStream IP for SP Series (TWAIN/TWAIN x64/ISIS), WIA Driver (16), PaperStream Capture Lite (18), Software Operation Panel, Error Recovery Guide, Scanner Central Admin, ABBYY™ FineReader Sprint™, Presto!™ PageManager™ |
| Image Processing Functions |
Multi image output, Automatic color detection, Automatic page size detection, Blank page detection, Dynamic threshold (iDTC), Advanced DTC, SDTC, Error diffusion, Dither, De-Screen, Emphasis, Dropout color (None/Red/Green/Blue/White/Saturation/Custom), sRGB output, Split image, De-Skew, Edge filler, Vertical streaks reduction, Digital endorser, Background pattern removal |
| Included Items |
AC adapter, USB cable, Setup DVD-ROM |
